DOBOT M1 is a cost-effective intelligent robotic arm for light industry. With high precision, wide working range, complete functions and secondary development, it provides users more ways to use. M1 can realize multiple functions of assembly line work such as soldering, visual recognition and PCB plug-in, helping to construct the intelligent industrial syste
PLUG AND PLAY , EASY TO MOVE
No complex installation is required, M1 can be connected just in one step. It’s so light that a single person can move anytime anywhere.
INTEGRATED MACHINE DESIGN
The integrated machine design greatly improves the work efficiency between the servo drive and the control system.
HIGH PRECISION AND 1.5KG PAYLOAD
The repetitive positioning accuracy of M1 can reach 0.02mm with a maximum working range of 400mm and a rated payload of 1.5kg, so as to ensure the best performance of the lightweight industrial robotic arm.
SIMPLE AND HANDINESS
The simple and concise mechanical structure enables M1 to work efficiently and it’s perfect for various assembly line work.
INTELLIGENT INTERFACE, WIDE APPLICATION
Standardized intelligent interface and open programming language make M1 highly extensible. With different accessories, M1 can realize diverse functions.
EFFICIENT DEPLOYMENT
With lightweight body, easy installation and various controls, M1 can help you quickly complete the work including production and packaging.
VISUAL SORTING
With the visual recognition suite, M1 can work like eyes to recognize and sort objects with different colors and shapes.
Parameters that Match Your Needs
| Model Number | M1 | |
|---|---|---|
| Weight(kg) | 15.7 | |
| Effective Payload(kg) | 1.5 | |
| Reach(mm) | 400 | |
| Repeatability?mm? | ±0.02 | |
| Power Supply | 100~240VAC, 50/60Hz | |
| Communication | TCP/IP, Modbus TCP, Modbus RTU | |
| Joint Range | J1 | ±85° |
| J2 | ±130° | |
| J3 | 5mm ~ 245mm | |
| J4 | ±360° | |
| Joint Maximum Speed | J1 | 180° /s |
| J2 | 180° /s | |
| J3 | 1000mm/s | |
| J4 | 1000° /s | |
