LINAK® produces electric linear actuator solutions to create smooth movement in a variety of very different applications. From healthcare to agriculture, comfort furniture, office interior, or industrial automation – the number of possibilities is almost endless. Explore and be inspired across the broad spectrum of business areas already serviced by LINAK.
Product filed under:
Actuators and Collaborative Actuators and Collaborative
Lifting columns extend the reach of cobot palletizers
Cobot palletizers are a valuable solution in material handling, as they free your workers from monotonous and physically demanding tasks.
However, collaborative robots with limited reach are prevented from stacking boxes beyond a certain height.
The LINAK® ELEVATE lifting column makes it possible to also palletize the upper levels. The cobot can be raised or lowered during palletizing to get the most advantageous working position. Also, it is economically viable to increase the cobot workspace with the column as 7th axis.
ELEVATE lifts your palletizer to the next level as it is:
- Fast: Load-independent speed up to 100 mm/sec and with optional simultaneous run
- Flexible: Integrated controller with digital and analog I/O options or Modbus TCP/IP
- Solid: Low deflection with 100 kg load and up to 1400 Nm dynamic bending moment
ELEVATE is an easy-to-install lifting column that is designed for cobot palletizers. Various mounting plates make it compatible with a wide range of cobot models. You choose between different communication interfaces to control the electric lifting column with your palletizer system: digital and analog I/O options (ELEVATE Easy and ELEVATE Pro) or Modbus TCP/IP (ELEVATE Modbus).
ELEVATE is offered with accessories to make the integration easy. Accessory kits include mounting plates and cables. In addition, cobot brand-specific driver software and components are provided, such as a URCap for cobots from Universal Robots and TMFlow for OMRON TM cobots. Use ELEVATE with your preferred components for power supply and safety relays.
Do you want to know more about the electric lifting column? ELEVATE uses our powerful LC3 IC.
